071M6

Insert Design Part No.: 071M6 Thread Size: M6 Pitch (internal): 1.00 Head Thickness T: 1.30 Head Diameter D: 9.50 Length L: 12.30 Hole Design Hole Diameter C: 7.7-8.2 Hole Depth Y: 12.50 Boss Diameter X: 14.60 Wall Thickness W: 3.20

004M6

Insert Design Part No.: 004M6 Thread Size: M6 Pitch (internal): 1.00 Head Thickness T: 1.00 Head Diameter D: 12.70 Length L: 7.70 Hole Design Hole Diameter C: 7.7-8.2 Hole Depth Y: 7.90 Boss Diameter X: 14.60 Wall Thickness W: 3.20

072M6

Insert Design Part No.: 072M6 Thread Size: M6 Pitch (internal): 1.00 Head Thickness T: 1.30 Head Diameter D: 9.50 Length L: 7.70 Hole Design Hole Diameter C: 7.7-8.2 Hole Depth Y: 7.90 Boss Diameter X: 14.60 Wall Thickness W: 3.20

003M5

Insert Design Part No.: 003M5 Thread Size: M5 Pitch (internal): 0.80 Head Thickness T: 0.90 Head Diameter D: 11.10 Length L: 10.10 Hole Design Hole Diameter C: 6.0-6.5 Hole Depth Y: 10.20 Boss Diameter X: 12.20 Wall Thickness W: 2.85

071M5

Insert Design Part No.: 071M5 Thread Size: M5 Pitch (internal): 0.80 Head Thickness T: 1.00 Head Diameter D: 7.90 Length L: 10.10 Hole Design Hole Diameter C: 6.0-6.5 Hole Depth Y: 10.20 Boss Diameter X: 12.20 Wall Thickness W: 2.85

004M5

Insert Design Part No.: 004M5 Thread Size: M5 Pitch (internal): 0.80 Head Thickness T: 0.90 Head Diameter D: 11.10 Length L: 6.60 Hole Design Hole Diameter C: 6.0-6.5 Hole Depth Y: 6.80 Boss Diameter X: 12.20 Wall Thickness W: 2.85

072M5

Insert Design Part No.: 072M5 Thread Size: M5 Pitch (internal): 0.80 Head Thickness T: 1.00 Head Diameter D: 7.90 Length L: 6.60 Hole Design Hole Diameter C: 6.0-6.5 Hole Depth Y: 6.80 Boss Diameter X: 12.20 Wall Thickness W: 2.85

003M4

Insert Design Part No.: 003M4 Thread Size: M4 Pitch (internal): 0.70 Head Thickness T: 0.75 Head Diameter D: 8.70 Length L: 8.50 Hole Design Hole Diameter C: 5.4-5.9 Hole Depth Y: 8.60 Boss Diameter X: 10.90 Wall Thickness W: 2.50

071M4

Insert Design Part No.: 071M4 Thread Size: M4 Pitch (internal): 0.70 Head Thickness T: 0.75 Head Diameter D: 7.10 Length L: 8.50 Hole Design Hole Diameter C: 5.4-5.9 Hole Depth Y: 8.60 Boss Diameter X: 10.90 Wall Thickness W: 2.50

004M4

Insert Design Part No.: 004M4 Thread Size: M4 Pitch (internal): 0.70 Head Thickness T: 0.75 Head Diameter D: 8.70 Length L: 5.60 Hole Design Hole Diameter C: 5.4-5.9 Hole Depth Y: 5.80 Boss Diameter X: 10.90 Wall Thickness W: 2.50

072M4

Insert Design Part No.: 072M4 Thread Size: M4 Pitch (internal): 0.70 Head Thickness T: 0.75 Head Diameter D: 7.10 Length L: 5.60 Hole Design Hole Diameter C: 5.4-5.9 Hole Depth Y: 5.80 Boss Diameter X: 10.90 Wall Thickness W: 2.50

003M3.5

Insert Design Part No.: 003M3.5 Thread Size: M3.5 Pitch (internal): 0.60 Head Thickness T: 0.75 Head Diameter D: 7.90 Length L: 7.00 Hole Design Hole Diameter C: 4.6-5.0 Hole Depth Y: 7.20 Boss Diameter X: 9.50 Wall Thickness W: 2.25

071M3.5

Insert Design Part No.: 071M3.5 Thread Size: M3.5 Pitch (internal): 0.60 Head Thickness T: 0.75 Head Diameter D: 6.40 Length L: 7.00 Hole Design Hole Diameter C: 4.6-5.0 Hole Depth Y: 7.20 Boss Diameter X: 9.50 Wall Thickness W: 2.25

004M3.5

Insert Design Part No.: 004M3.5 Thread Size: M3.5 Pitch (internal): 0.60 Head Thickness T: 0.75 Head Diameter D: 7.90 Length L: 4.10 Hole Design Hole Diameter C: 4.6-5.0 Hole Depth Y: 4.20 Boss Diameter X: 9.50 Wall Thickness W: 2.25

003M3

Insert Design Part No.: 003M3 Thread Size: M3 Pitch (internal): 0.50 Head Thickness T: 0.75 Head Diameter D: 7.10 Length L: 5.20 Hole Design Hole Diameter C: 3.7-4.0 Hole Depth Y: 5.30 Boss Diameter X: 7.40 Wall Thickness W: 1.70

004M3

Insert Design Part No.: 004M3 Thread Size: M3 Pitch (internal): 0.5 Head Thickness T: 0.75 Head Diameter D: 7.10 Length L: 4.1 Hole Design Hole Diameter C: 3.7-4.0 Hole Depth Y: 4.2mm Boss Diameter X: 7.40 Wall Thickness W: 1.70
